How to Use the Nec Display Wall Calibrator Serial Number to Achieve Perfect Uniformity in Your Video Wall

If you have a video wall composed of multiple Nec displays, you might want to use the Nec Display Wall Calibrator software to automatically adjust the color and brightness of each display to create a seamless and consistent visual experience. The software communicates with each display via RS232 or LAN and uses internal test patterns to measure and correct the color characteristics of each display. The software also uses 10 bit internal Look Up Tables (LUTs) to calibrate the grayscale and gamma of each display without reducing the number of displayable colors or introducing banding artifacts.

To use the Nec Display Wall Calibrator software, you will need a color sensor that is connected via USB to a host PC. The color sensor is placed on the screen and a series of test patterns is generated and measured. This process is repeated for all displays in the video wall. The software then calculates the optimal settings for each display and applies them automatically. You can also save the display configurations, measurements, and calibration data as a project file for later reference, re-calibration, or restoring of settings.

One of the important steps in using the Nec Display Wall Calibrator software is to enter the serial number of each display in the video wall. The serial number is a unique identifier that allows the software to recognize each display and apply the correct settings. The serial number can be found on a label on the back of each display or on the OSD menu under Information. You can also use the Nec NaViSet Administrator 2 software to remotely access and view the serial number of each display.

To enter the serial number of each display in the Nec Display Wall Calibrator software, you need to follow these steps:


Launch the Nec Display Wall Calibrator software on your host PC.
Select New Project from the File menu or click on the New Project icon on the toolbar.
Enter a name for your project and click OK.
Select your color sensor from the drop-down list and click OK.
Select your communication method (RS232 or LAN) from the drop-down list and click OK.
Enter the number of rows and columns in your video wall and click OK.
Click on each display icon on the grid and enter its serial number in the Serial Number field. You can also use the Auto Detect button to automatically detect and fill in the serial numbers of all displays connected via LAN.
Click OK when you have entered all serial numbers.
You can now proceed with measuring and calibrating each display using the color sensor and the internal test patterns.


By using the Nec Display Wall Calibrator serial number, you can ensure that each display in your video wall is correctly identified and calibrated by the software. This will result in a perfect uniformity across your video wall that will impress your viewers and enhance your visual content. 9d9bd590cd
