Another piece made with a custom build physical modelling environment in SuperCollider and Python.

The virtual instrument used is a plate with 16 strings attached. The strings are tuned in a harmonic ratio, but by changing their mass ratio with respect to the plate the resulting overall sound will be more or less harmonic due to there being more or less sympathetic vibrations.

All sound synthesis and sequencing done in SuperCollider.

Disparity

Another experiment in using physical modelling sound synthesis. This time the model used is a system of 4 inter-connected plates. The plates are excited using variable length sequences of pre-filtered digital impulses. The frequency of the impulses is set equal to one of the first twelve mode frequencies of the first two plates. These sounds are then layered to create chords and hence the harmonic structure of the piece is derived entirely from the spectral content of the first two plates.

All sound synthesis done in SuperCollider, all numerical math done with the help of Python (using Numpy and Scipy). This is a stereo reduction of the original 24-channel version.

Extase 1

Made With SuperCollider, Python and a little help from Audacity

Extase 4 (Version)

Made with SuperCollider, Python and a little help from Audacity.

Extase 3 (Version)

An experiment from 2008 mapping the Lorenz system to various granular synthesis parameters like grain position, grain trigger frequency, grain filter frequency, grain amplitude and spatial position. Various loops were obtained which were then layered and offset to obtain the final result.

GR01

Another piece (stereo version) made with a self-build physical modelling library for SuperCollider and Python. The model used for the sounds consists of two plates which are connected to each other through 6 stiff strings of different physical proportions.

The different spectral content throughout the piece is achieved by exciting different strings and plates and, by picking up the response of all individual objects at different locations along their surface.

The excitation signals are made up from different types of filtered noise and impulses (FOF synthesis) and an attempt has been made to model / compose different types of environmental sound scenes purely using sound synthesis methods.

All sound synthesis and sequencing done in SuperCollider using Unit Lib and my custom physical modelling lib.

Extase 2, 3 & 4

H is the result of my MA graduation research on algorithmic composition methods based on the Schrödinger equation from quantum mechanics. Various curves obtained from calculating the solution of the Schrödinger equation for the hydrogen atom are used to control granular synthesis parameters. These curves are also used to structure and shape sound events: musical segments typically lasting between 10 to 60 seconds consisting out of individual granular clouds which evolve spectrally and dynamically over the duration of an event.

The curves are also used for probability tables which are used to generate control data for the thousands of individual grains making up a granular cloud and to statistically determine the durations, ordering and timing of events. All calculations, structuring and generation of the synthetic sounds is done in real-time by the computer. This is accomplished by executing scheduled segments of code, which contain instructions for the computer for what to do next and how it should do this. One might say the computer becomes a genuine performer which "reads" from a score and acts in response to this. The result is that the piece is not static, but will contain subtle differences every time it is played.

Made with one of my first granular Max / MSP patches.

Improvisation#3

This track demonstrates an SC based environment for modelling coupled string vibration using a hybrid finite difference/modal approach. In SC you can specify the setup of the string network, i.e. how many strings you want to include, their physical parameters and boundary conditions and their inter-connection location. This information will then be send on to Python, which translates this in a suitable finite difference formulation in state space form. This means the complete system can be put into one giant matrix, which can be diagonalized to find the eigenvalues and eigenvectors of the system. From the eigenvalues the modes and damping constants of the complete system may be determined easily. This information is send back to SuperCollider and is used to provide the filter coefficients of a parallel bank of second-order resonators which when excited will generate the sound output.

The advantage of the finite difference formulation is that one has a lot of freedom in assembling the network of inter-connected objects and determining the inter-connection locations in that it is a very general approach. The downside is that the computational complexity of finite difference based models is usually rather large, making it unsuitable for real-time applications. This is where the diagonalisation to modal coordinates proves to be very valuable, since you end up with a large array of filter coefficients representing the modes of the complete system. One can then discard all modes which have a minor contribution (i.e. by excluding all modes below a certain threshold amplitude) and hence end up with a hugely more efficient model. Another nice feature of having your system expressed in modal coordinates is that it becomes possible to use simple second-order resonators readily available in SuperCollider (or any other audio environment for that matter) to simulate the system. The limitation of the modal formulation is that it is only possible to simulate linear systems though. Python was used because it has an excellent library (Numpy and Scipy) for doing more complex numerical computations (i.e. support for sparse matrices, diagonalising matrices, solving large linear systems efficiently), which are not possible to do (efficiently at least) with SuperCollider.

For this composition the environment was used to model two inter-connected strings. The strings are fixed at one side and free and inter-connected at the other side. The physical parameters of the string system are tuned so that the sound output sounds (pleasantly) harmonic, which was a long trial and error process. The string network is excited using various synthetically generated excitation signals.

All sound synthesis/design and sequencing was done entirely in SuperCollider. The overall structure of the composition is fixed, although micro-fluctuations will occur everytime the piece is played making every listening experience a little unique (at least that is the idea).

Excite Me

All sounds for this composition originate from a physical model of a stiff plate with 6 differently tuned strings attached to it. Throughout the piece the plate is excited using different synthetically generated excitation signals consisting of filtered single sample impulses and filtered noise. The different sounds are obtained by picking up the vibrations of the model on different locations along the plate and the strings.

All sound synthesis and sequencing done in SuperCollider (with a little help from Python for all the numerical maths stuff).
