New York Modular Society is excited to start off Patchable with a standard. The 3 module challenge! The rules are simple, you can use any three modules you want, no restrictions. Output modules do not count. If you want to use a sequencer, a full voice module and something else that is totally cool! Or get crazy with a random,VCA and delay module. The choice is yours. Get patching!

PATCHABLE 0001 - 3 MODULE CHALLENGE

Crew Called Self - Expanding Limitations - PATCHABLE - 0001

Created for New York Modular Society Patchable-0001

The three modules used for this patch are Maths, QPAS & Mimeophon.  Not other modules, effects or post processing was done.

Patch Notes:
The basic idea is Maths channel 4 clocks the Mimeophon and output goes to QPAS level and Freq 1 so the audio and delay are synced.  I am using Maths ch1 as a VCO into the QPAS. I also mult the Mimeophon output into Maths ch 3 to control feedback going into Freq 2 on QPAS. There was an awful lot of knob turning and button pushing happening in the patch.

This is the main patch, but does not cover everything.
- Maths ch 4 in cycle, slow
- Maths EOC out to Mimeophon clock in
- Maths ch 1 in cycle, fast (audio rate)
- Maths ch 1 out > QPAS left in
- QPAS stereo lowpass out to Mimeophon
- Mimeophon right output to Maths ch 3
- Maths ch 3 output to QPAS Freq 2

Mimqpaaths-PATCHABLE-0001

Sample and Hold from Behringer Neutron into A, B, Control, Drive and Resonance on Vult Freak Module (used onboard attenuverters) into iPad for Eventide effects.

I cycled through all of the filter models on the Freak as well as each of the modes of the filter (hp, lp, notch, band, etc.) trying to find little sweet spots. I think I found some!

Tim PATCHABLE-0001

Made for the first NYMS's firs Patchable: https://nyms.love/2019/08/23/patchable-0001/

My patch used Sprot, Erbe-Verb, and QPAS hooked up in a feedback loop. Sprott's ban-dpass our when into Erbe-Verbe, then  Erbe-Verbe's audio outs went into QPAS. QPAS's left band-pass out went back into Sprott's VCA in and it's smile-pass outs were recorded. Erbe-verbe's CV out went to it's absorb, into Sprott's VCA (inverted), and QPAS's radiate (R inverted) and Q (inverted). This was used to keep the feedback from going too far out of control. The chaos-pass out from the Sprott was patched back into the VCA diode. Additionally, Sprott's band-pass and chaos-pass were patched into QPAS's FREQ input , and it's low-pass and chaos-pass were patched into QPAS's !!¡¡ inputs. The high-pass and low-pass outs were patched into the remaining attenuverted inputs on Sprott. Additional noise was provided by grounding a cable connected to Erbe-Verb's CV out.

dev/null

Exoplanetary Aerobrake Maneuver PATCHABLE-0001

For the Repatch challenge, this month I'm challenging myself to do all the NYMS Patchable challenges I haven't done yet, in order. This is #1, the Three Module Challenge.

Modules are: pamela’s new workout, doepfer a-106-5 sem filter, monsoon in resonestor mode.
Patch notes at https://nyms.love/2019/08/23/patchable-0001/
