A set of handwound Alnico II Jazzmaster pickups, 5.6k neck and 10.8k bridge, nice set!

A2 JM Set

A2 Jazzmaster Pickups 7k1 Neck 7K7 Bridge

A2 7k1 7k7 Set

Handwound Alnico 2 Jazzmaster pickups, 7k6 neck 8k4 bridge

A nice set of Strat pickups, Alnico 4 on the low strings, Alnico 2 on the high, RWRP, lightly potted, 42 AWG Plain Enamel wire.

Handwound Alnico 4/2 split magnet Strat set, Plain Enamel

Alnico 2 "Porker Neck" pickup, wound to 4k6 with 40awg Heavy Enamel wire.  A bunch of fat juicy pork in the neck position without the muddies.  Gets a little of that Charlie Christian tone without going to a blade/bar magnet setup and 38awg wire.  Makes a nice pair with my A4 P-90JM!

A2 Porker Neck And A4 P - 90JM

A nice 10k Broadcaster style bridge pickup for Tele, 43awg plain enamel wire, black hemp string wrap, raw steel baseplate.  Flash wax potted, a really nice versatile bridge pickup for Teles, but especially great in an Esquire!

A3 10k Broadcaster Bridge Pickup

A pair of Fat 52's Jazzmaster pickups, Alnico 5 on the wound strings, Alnico 2 on the plain.  Running through the different pickup positions, first with 1 meg pots, then 250k, then a little ditty context.

"Fat 52's" Jazzmaster Pickups Alnico 5/2

Alnico 2 Porker Jazzmaster neck pickup and Alnico 5 JMP90 bridge pickup in middle position on rhythm, JMP90 on lead with much gain.

A2 Porker Neck A5 JMP90 Bridge Parallel JMP90 Lead

Alnico V Jazzmaster pickups with 42awg Formvar wire

A5 Formvar Classics

Alnico 5 Jazzmaster Pickups with 42awg Plain Enamel wire

A5 Classics PE

Neck pickup is Alnico V with inner ~50% of the coil (4600 turns) 43 awg Plain Enamel wire,  outer ~50% (4000 turns) 42 awg Plain Enamel, wound to 8k3 (about equivalent output to ~7k5 42 awg Jazzmaster pickup).  Bridge pickup is a Jazzmaster/P90 hybrid with fixed steel poles, 42awg Heavy Formvar wire, and one Alnico IV bar magnet and one Alnico V "unoriented" bar magnet, wound to 9k (10,000 turns).

Tim Esau's Album

Alnico V 42/43awg "Mezcla" Jazzmaster Neck Pickup, Alnico IV/Alnico V Unoriented JMP90 Bridge Pickup

Sunday Handwired Pickups "Woodchime" Alnico 2 Jazzmaster Pickups
42 awg Heavy Formvar, 8000 turns 7k1 neck, 9200 turns 8k8 bridge

Sunday Handwired Alnico 2 "Woodchime" Jazzmaster Pickups

Alnico 2 "Woodies" Jazzmaster Pickup Set
42awg Plain Enamel wire, 8000 turns/7k2 neck, 9500 turns 8k9 bridge


Sunday Handwound Alnico 2 Woodies Plain Enamel

A nice set of split magnet Alnico 5/2 Jazzmaster pickups.  A5 on the EAD strings, A2 on GBe.  Neck is wound 8000 turns/7k1, bridge 9300 turns/8k4 with 42awg Heavy Formvar wire.

Sweet 52's Jazzmaster Set

A nice set of Jaguar pickups that feature weaker Alnico 4 magnets and a mild overwind to get more mids and bottom end while maintaining all the top end clarity and detail.  No icepick treble, just smooth twang and soul.

A4 Tomcat Jaguar Pickup Set

Sunday Handwound Alnico 2 Woodchime Jazzmaster Neck pickup with JM-Broadcaster Bridge pickup

A test of a set of WRHB-alikes in Jazzmaster covers, Alnico 2 rod magnets under the covers and FeCrCo 2 threaded rods exposed.  First part has them with 1 Meg pots, second has 500k pots.  I am loving the clarity and huge WRHB sound with the 1 Megs.

JM WRHB 1meg vs 500k

JM-EXII Electric XII pickups in Jazzmaster covers

H-90 Proto

H-90 Proto 2

An improved take on Firebirds, thicker steel plate adds some lows and really gets things sounding sweet.

Sunday Handwound Firebirds

A nearly Jazzmaster pickup in a humbucker format shell, .531" magnets help make up for the taller, narrower, and lower turn count coil.  it is almost a JM and just as sweet.  The bridge pickup is a prototype for a nearly P-90 voiced humbucker.  Together there is some pretty serious magic going on...

JM-HB .531 neck, H-90 Proto bridge

Alnico 4 P-90 wound to 8k3 in my test mule tele in the bridge position.

8k3 Alnico 4 P-90

Silvertone 1446/Harmony Rocket with Alnico 2 P-90's

Alnico 2 rod 90 neck Alnico 4 P-90 bridge part 2

Handwound Filtertron style pickups with 1/4" thick Alnico 5 magnets and vintage spec covers, bobbins, and baseplates.

Alnico 5 "Sunday-Trons" Filtertron style Neck and Bridge pickups

Test clip of the JM-Bucker Prototype I hum cancelling Jazzmaster pickup

JM-Bucker Proto I Hum cancelled Jazzmaster pickup

The Bends, a MKIII Tonebender variant running into an Oceanic Deluxe 2-in-1 Reverb and delay pedal.

Oceanic Deluxe and the Bends

1776 Effects' Multiplex built for Con-tiki at OSG
