Fully equipped multimode filter based on NJM2069 chip found on DW-8000 and Poly-800 synthesizers.

Fonoton 2069 Multimode Filter Demo

A demo of the Bard Vacuform VCF for the MW community. This is a tube implementation of the famous Steiner-Parker Synthacon multi-mode filter using a 6н3п Soviet double-triode and two EAA91 double-diodes. Time marks are as follows:
0:00–0:15- Dry Signal; Metasonix R55 and R54 into an R53

0:15–0:31- Lowpass; resonance at about 10:30

0:31–0:47- Lowpass, plus reverberated “dry” into bandpass; Resonance at about 10:30

0:47–2:06- Manual Lowpass sweeps; resonance at 7:00 (Zero Resonance), 9:00, 10:30, 12:00, 1:30, 3:00, and 5:00 (Full Resonance/Self-Oscillation)

2:06–3:08- Manual Bandpass sweeps; resonance at 7:00 (Zero), 9:00, 12:00, 3:00, and 5:00 (Full)

3:08–4:19- Manual Highpass sweeps; resonance at 7:00 (Zero), 9:00, 12:00, 3:00, and 5:00 (Full)

4:19–end- Manually sweeping filter with all inputs in use. LP is R53 in self-oscillation, BP is R54, and HP is R55

Pardon my jittery hand during the sweeps; I tried to keep it as steady as possible.
