Telecaster bridge pickup through the PBSD Cyanotype Preamp, based on the Chase Tone Secret Preamp/Echoplex Preamp.

All mode settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Agile TC-630 Telecaster (Drop C#)-->Cyanotype-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

SoundCloud Uploads

Tele Cyanotype Preamp Demo

Eastwood Sidejack (P90)through the PBSD Cyanotype Preamp, based on the Chase Tone Secret Preamp/Echoplex Preamp.

All mode settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Eastwood Sidejack P90-->Cyanotype-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

Eastwood Cyanotype Preamp Demo

Gibson Faded SG through the PBSD Cyanotype Preamp, based on the Chase Tone Secret Preamp/Echoplex Preamp.

All mode settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Gibson Faded SG-->Cyanotype-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

SG Cyanotype Preamp Demo

Fender Eric Clapton Strat (MIM) through the PBSD Cyanotype Preamp, based on the Chase Tone Secret Preamp/Echoplex Preamp.

All mode settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Strat-->Cyanotype-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

Strat Cyanotype Preamp Demo

Gibson Faded SG through the PBSD Post Mortem Distortion, based on the Boss HM-2

Multiple settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Gibson Faded SG-->Post Mortem-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

Demos

SG Post Mortem Distortion

Eastwood Sidejack (P90)through the PBSD Post Mortem Distortion, based on the Boss HM-2.

Multiple settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Eastwood Sidejack P90-->Post Mortem-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

Eastwood Post Mortem Distortion

Fender Eric Clapton Strat (MIM) through the PBSD Post Mortem Distortion, based on the Boss HM-2.

Multiple settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Strat-->Post Mortem-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

Strat Post Mortem Distortion

Telecaster bridge pickup through the PBSD Post Mortem Distortion, based on the Boss HM-2.

Multiple settings are presented with volume changes on the guitar and the pedal.

Signal Chain:
Agile TC-630 Telecaster (Drop C#)-->Post Mortem-->1973 Fender Twin Reverb (Vibrato Channel)

Zoom R24 Interface-->Audacity (FLAC)
Close Mic (left channel) SM57
Room Mic (right channel) SM58

Tele Post Mortem Distortion

Guitar: Fender Thinline Telecaster with P90s
*.013 Gauge Strings tuned to Bb Standard
Pedals: PBSD Mystic Distortion, Impressionist Delay
Amp: '73 Fender Twin with Jensen Ceramic Speakers, Vibrato channel, see SG demo for settings.
Recording: Mac Mini Logic Pro, Focusrite Scarlett 2i2 (recent), SM57 6 inches slightly off center from speaker cone. 80dB in room.

Mystic Distortion Demo-P90 Tele

Guitar: Gibson SG Special Faded
*.010 Gauge Strings tuned E Standard
Pedals: PBSD Mystic Distortion, Impressionist Delay
Amp: '73 Fender Twin with Jensen Ceramic Speakers, Vibrato Channel, see picture for settings.
Recording Notes: Mac Mini Logic Pro, Focusrite Scarlett 2i2 (recent), SM57 6 inches slightly off center from speaker cone. 80dB in room.

Mystic Distortion Demo-SG
